| Network Switch - Synerg™ P10G |
|
Description
| |
| Description |
S-CUBE™'s latest generation of Web Smart Ethernet Switches unify plug-and-play simplicity with incomparable performance and reliability to create a cost-effective solution for work groups, departments and Home. Its IEEE 803.3af capable 4 POE ports are capable of providing power and data from a single point, which makes users to easily connect and supply power to Power over Ethernet (PoE) devices such as wireless Access Points (APs), IP phones, and IP cameras. Enhanced features of the Synerg™ P10G include 2 Gigabit SFP combo ports, QoS, and versatile management functions.
The Synerg™ P10G is housed in a new style 9" rack mount case with an easy-to-view front panel and diagnostic LEDs. User-friendly, web-based management is supported for easy configuration and flexibility for different network requirements.
|
| |
| Features |
| RoHS Complaint |
S-CUBE™'s Synerg™ P10G switches complies with RoHS (Restriction of Hazardous Substances) RoHS directives restrict the use of specific hazardous materials during the manufacture of electrical and electronic goods.
You can also manage the switches from a remote station using the Trusted Host function. Management can be from up to five designated management stations through a web browser or telnet session from any ports.
|
| |
| Secure Network |
| The Synerg™ P10G provides a robust set of security features normally found only in fully managed switching solutions. the switches provide support for secure encrypted 802.1X Port-based Authentication, Broadcast Storm Control, and up to 256 static MAC address entries.
|
| |
| IEEE 802.1Q VLAN Tagging |
| VLANs allow your network to be segmented into Departmental, Hierarchical, and Security groups and place a “tag” in a frame to identify which VLAN it belongs to. This allows 802.1Q-compliant devices to work seamlessly together to manage VLAN traffic.
|
| |
| Asymmetric VLANs |
| Asymmetric VLANs are also supported by the Synerg™ P10G. With this feature enabled, VLAN groups can send information to each other without the traffic going through a router or a Layer 3 switch. This eliminates expense and maximizes efficiency while maintaining security.
|
| |
| 802.1p Priority Tagging or DSCP-based QoS |
| The Synerg™ P10G allows users to prioritize traffic based on 802.1p or DSCP-based (Differentiated Services Case Point) QoS. Port-based QoS prioritizes all port traffic with one value, while 802.1p classifies frames according to their VLAN tag. DSCP-based QoS prioritizes traffic according to its IP header. DSCP-based QoS and 802.1p priority tagging prioritizes traffic such as VoIP as it enters the switch, ensuring that your data is always clear and jitter-free.
|
| |
| Link Aggregation |
| The Synerg™ P10G supports Static Link Aggregation with port trucking, which “trunks” multiple ports together to function as a single, high-bandwidth channel. When a high-bandwidth channel is needed to uplink to another switch, Link Aggregation makes this process simple and hassle-free.
|
| |
| IGMP Snooping |
| IGMP Snooping allows for the forwarding of multicast packets, such as streaming audio and video, without increasing network congestion. By snooping IGMP registration information within a frame, a list of workstations in the multicast group is created. The switch uses this list to intelligently forward packets to the appropriate workstations
|
| |
| Cable Diagnostics |
| Because your connection is just as important as the switch itself, the Synerg™ P10G is designed with a cable diagnostic feature that detects transmission errors and the condition of cables attached to the switch's Gigabit copper ports. Cable Diagnostics make it easier to troubleshoot cabling issues through a web-based interface and keep all connections up.
|
| |
| Advanced Management Features |
| The Synerg™ P10G supports 802.1D Spanning Tree, RSTP, MSTP, which provides protection from universal cabling loops forming within a network infrastructure. Spanning tree detects and breaks these loops, ensuring network uptime.
|
| |
| Management Utility |
In addition to the Web-based Management Interface, the Synerg™ P10G also ships with the S-CUBE™ SmartCLI Utility. This utility provides a valuable tool in managing, planning, and troubleshooting network configurations. Managing our Web Smart switch takes few minutes. It is fully loaded with user help for each and every command with uses Example. The Smart CLI Utility also includes:
Discovery List - Automatically detects and displays up to 254 S-CUBE Web Smart Switches on your network along with their MAC addresses.
Monitor List - Monitors switch status and any trap messages sent to a designated station.
Device Configuration - Allows the administrator to set up the switch's IP Address, Subnet Mask, Gateway, System Name, Password, and Location.
With its green sensibility and easy-to-use, robust feature set, Synerg™ P10G makes a great solution for any growing business.
|
| |
| Specification |
| Interface |
| Ports | |
- 4 10/100 BASE-T Auto-negotiating, Auto MDI/MDI-X ports with 802.3 Flow Control.
- 4 10/100 BASE-T POE enabled Auto-negotiating, Auto MDI/MDI-X ports, 802.3 Flow Control with 802.3af Power over Ethernet.
|
| Combo Ports | |
- 2 (SFP) can be used as Gigabit Fiber optic/ Copper Port
|
| LED Indicators | |
- Per device: Power/PWR Error Port LED, Mode Indicator: Link/Act Mode
- Per 10/100 BASE-T port: Link/Act
- Per SFP slot: Link/Act/error, 1000Mbps
|
| Performance |
| Packet Forwarding Rate | |
|
| MAC Address Table Size | |
|
| MAC Address Update | |
- Up to 256 static MAC entries
- Enable/disable auto-learning of MAC addresses
|
| Packet Buffer | |
|
| Physical & Environmental |
| Power Consumption | |
|
| Power Adaptor Input | |
- 220 to 240 VAC 50/60Hz internal universal power supply
|
| Temperature | |
- Operating: 0° to 60°C
- Storage: -10° to 45° C
|
| Humidity | |
- Operating: 10% to 90% Non-condensing
- Storage: 5% to 90% Non-condensing
|
| Dimensions (W x D x H) | |
|
| RoHS-compliant | |
|
| Software Specifications |
| Port Standards and Functions | |
- IEEE 802.3 10BASE-T Ethernet
- IEEE 802.3u 100BASE-TX Fast Ethernet
- IEEE 802.3ab 1000BASE-T Gigabit Ethernet
- IEEE 802.3z Gigabit Ethernet (fiber) ANSI/IEEE 802.3
- IEEE 802.3x Flow Control
- Auto-Negotiation
- 802.3af Power over Ethernet
|
| L2 Features | |
- IGMP v1/2 Snooping: supports 64 multicast groups
- 802.1D Spanning Tree
- 802.1W Rapid Spanning Tree
- 802.1S Multi VLAN Spanning Tree
- Static Port Trunk (Link Aggregation): up to 6 groups per device, up to 8 ports per group
|
| VLAN | |
- Port based and 802.1Q VLAN (VLAN Tagging)
- Up to 256 static VLAN groups
- 802.1Q VLAN support for the full 4,096 VLAN IDs
- Double Tagging(Q in Q)
- Management VLAN
- Asymmetric VLAN
|
| Quality of Service (QoS) | |
- 802.1p Priority Queues
- Up to 4 queues per port
- DSCP-based QoS
- Type of Service/DS
- Priority Override (DA,SA,VID),Remap
|
| Security | |
- 802.1X Port-based Access Control
- Broadcast Storm Control, Egress Rate Shaping
- Trusted Host
- Cable Diagnostics function
|
| Management | |
- Web-based GUI
- DHCP Client
- POE events, system events, fiber port events, twisted-pair port events
- Port Access Control
- Web-based: Configuration restoration
- Web-based: Firmware upload
- Firmware upgrade using SmartCLI Utility
- System Reboot using web-based interface
- SmartCLI Utility
|
| Warranty Information |
| Warranty | |
|
|
Features
| |
| Features |
| RoHS Complaint |
S-CUBE™'s Synerg™ P10G switches complies with RoHS (Restriction of Hazardous Substances) RoHS directives restrict the use of specific hazardous materials during the manufacture of electrical and electronic goods.
You can also manage the switches from a remote station using the Trusted Host function. Management can be from up to five designated management stations through a web browser or telnet session from any ports.
|
| |
| Secure Network |
| The Synerg™ P10G provides a robust set of security features normally found only in fully managed switching solutions. the switches provide support for secure encrypted 802.1X Port-based Authentication, Broadcast Storm Control, and up to 256 static MAC address entries.
|
| |
| IEEE 802.1Q VLAN Tagging |
| VLANs allow your network to be segmented into Departmental, Hierarchical, and Security groups and place a “tag” in a frame to identify which VLAN it belongs to. This allows 802.1Q-compliant devices to work seamlessly together to manage VLAN traffic.
|
| |
| Asymmetric VLANs |
| Asymmetric VLANs are also supported by the Synerg™ P10G. With this feature enabled, VLAN groups can send information to each other without the traffic going through a router or a Layer 3 switch. This eliminates expense and maximizes efficiency while maintaining security.
|
| |
| 802.1p Priority Tagging or DSCP-based QoS |
| The Synerg™ P10G allows users to prioritize traffic based on 802.1p or DSCP-based (Differentiated Services Case Point) QoS. Port-based QoS prioritizes all port traffic with one value, while 802.1p classifies frames according to their VLAN tag. DSCP-based QoS prioritizes traffic according to its IP header. DSCP-based QoS and 802.1p priority tagging prioritizes traffic such as VoIP as it enters the switch, ensuring that your data is always clear and jitter-free.
|
| |
| Link Aggregation |
| The Synerg™ P10G supports Static Link Aggregation with port trucking, which “trunks” multiple ports together to function as a single, high-bandwidth channel. When a high-bandwidth channel is needed to uplink to another switch, Link Aggregation makes this process simple and hassle-free.
|
| |
| IGMP Snooping |
| IGMP Snooping allows for the forwarding of multicast packets, such as streaming audio and video, without increasing network congestion. By snooping IGMP registration information within a frame, a list of workstations in the multicast group is created. The switch uses this list to intelligently forward packets to the appropriate workstations
|
| |
| Cable Diagnostics |
| Because your connection is just as important as the switch itself, the Synerg™ P10G is designed with a cable diagnostic feature that detects transmission errors and the condition of cables attached to the switch's Gigabit copper ports. Cable Diagnostics make it easier to troubleshoot cabling issues through a web-based interface and keep all connections up.
|
| |
| Advanced Management Features |
| The Synerg™ P10G supports 802.1D Spanning Tree, RSTP, MSTP, which provides protection from universal cabling loops forming within a network infrastructure. Spanning tree detects and breaks these loops, ensuring network uptime.
|
| |
| Management Utility |
In addition to the Web-based Management Interface, the Synerg™ P10G also ships with the S-CUBE™ SmartCLI Utility. This utility provides a valuable tool in managing, planning, and troubleshooting network configurations. Managing our Web Smart switch takes few minutes. It is fully loaded with user help for each and every command with uses Example. The SmartCLI Utility also includes:
Discovery List - Automatically detects and displays up to 254 S-CUBE Web Smart Switches on your network along with their MAC addresses.
Monitor List - Monitors switch status and any trap messages sent to a designated station.
Device Configuration - Allows the administrator to set up the switch's IP Address, Subnet Mask, Gateway, System Name, Password, and Location.
With its green sensibility and easy-to-use, robust feature set, the Synerg™ P10G makes a great solution for any growing business.
|
Specification
| Interface |
| Ports | |
- 4 10/100 BASE-T Auto-negotiating, Auto MDI/MDI-X ports with 802.3 Flow Control.
- 4 10/100 BASE-T POE enabled Auto-negotiating, Auto MDI/MDI-X ports, 802.3 Flow Control with 802.3af Power over Ethernet.
|
| Combo Ports | |
- 2 (SFP) can be used as Gigabit Fiber optic/ Copper Port
|
| LED Indicators | |
- Per device: Power/PWR Error Port LED, Mode Indicator: Link/Act Mode
- Per 10/100 BASE-T port: Link/Act
- Per SFP slot: Link/Act/error, 1000Mbps
|
| Performance |
| Packet Forwarding Rate | |
|
| MAC Address Table Size | |
|
| MAC Address Update | |
- Up to 256 static MAC entries
- Enable/disable auto-learning of MAC addresses
|
| Packet Buffer | |
|
| Physical & Environmental |
| Power Consumption | |
|
| Power Adaptor Input | |
- 220 to 240 VAC 50/60Hz internal universal power supply
|
| Temperature | |
- Operating: 0° to 60°C
- Storage: -10° to 45° C
|
| Humidity | |
- Operating: 10% to 90% Non-condensing
- Storage: 5% to 90% Non-condensing
|
| Dimensions (W x D x H) | |
|
| RoHS-compliant | |
|
| Software Specifications |
| Port Standards and Functions | |
- IEEE 802.3 10BASE-T Ethernet
- IEEE 802.3u 100BASE-TX Fast Ethernet
- IEEE 802.3ab 1000BASE-T Gigabit Ethernet
- IEEE 802.3z Gigabit Ethernet (fiber) ANSI/IEEE 802.3
- IEEE 802.3x Flow Control
- Auto-Negotiation
- 802.3af Power over Ethernet
|
| L2 Features | |
- IGMP v1/2 Snooping: supports 64 multicast groups
- 802.1D Spanning Tree
- 802.1W Rapid Spanning Tree
- 802.1S Multi VLAN Spanning Tree
- Static Port Trunk (Link Aggregation): up to 6 groups per device, up to 8 ports per group
|
| VLAN | |
- Port based and 802.1Q VLAN (VLAN Tagging)
- Up to 256 static VLAN groups
- 802.1Q VLAN support for the full 4,096 VLAN IDs
- Double Tagging(Q in Q)
- Management VLAN
- Asymmetric VLAN
|
| Quality of Service (QoS) | |
- 802.1p Priority Queues
- Up to 4 queues per port
- DSCP-based QoS
- Type of Service/DS
- Priority Override (DA,SA,VID),Remap
|
| Security | |
- 802.1X Port-based Access Control
- Broadcast Storm Control, Egress Rate Shaping
- Trusted Host
- Cable Diagnostics function
|
| Management | |
- Web-based GUI
- DHCP Client
- POE events, system events, fiber port events, twisted-pair port events
- Port Access Control
- Web-based: Configuration restoration
- Web-based: Firmware upload
- Firmware upgrade using SmartCLI Utility
- System Reboot using web-based interface
- SmartCLI Utility
|
| Warranty Information |
| Warranty | |
|
| * The Product specifications, size and shape are subject to change without notice, and actual product appearance may differ from that depicted herein. |
| |
|
|
| |
|
